PXIe-1435 Image Acquisition Device

PXIe-1435 Image Acquisition Device

Product Details Introduction

Product Description of PXIe-1435 Image Acquisition Device

PXIe-1435 is a PXI Express (PXIe) bus image acquisition device launched by National Instruments (NI) in the United States. It is positioned as a high-speed image acquisition core component in the field of machine vision and automation testing, and can adapt to various configurations of Camera Link cameras. It has Camera Link Power Supply (PoCL) function, which can achieve fast acquisition and transmission of high-quality image data and is widely applicable to various high-precision visual inspection and image analysis scenarios. The core information is as follows:

1、 Core technical characteristics

-Multi specification camera adaptation: Camera Link cameras that fully support Base, Medium, Full, and Extended Full configurations are compatible with visual capture devices with different resolution and frame rate requirements, and have a wide range of adaptability;

-Integrated power supply function: Supports Power over Camera Link (PoCL) technology, which can directly power the camera through the Camera Link cable without the need for additional power modules, simplifying system wiring and integration complexity;

-High speed bus transmission: relying on the PXIe bus architecture, high-speed and low latency transmission of image data is achieved, ensuring efficient flow of massive image data from acquisition to storage/processing, and adapting to real-time visual analysis requirements;

-High reliability design: compliant with industrial safety standards, with good electromagnetic compatibility and environmental adaptability. In case of equipment damage, it needs to be repaired by professional personnel to avoid unauthorized modifications and ensure long-term stable operation;

-Convenient system integration: It needs to be used in conjunction with Camera Link cameras, dedicated cables, and other components to support seamless integration with NI related hardware and software platforms, simplifying the process of building and debugging visual inspection systems.

2、 Core application areas

-Industrial visual inspection: suitable for product defect detection, size measurement, appearance recognition and other scenarios in automated production lines, such as electronic component pin detection, automotive component assembly verification, to ensure product quality;

-Precision Manufacturing and Metrology: Adapt to the visual positioning and dimensional calibration of precision machining equipment, such as semiconductor chip packaging inspection, 3C product precision component assembly guidance, to improve manufacturing accuracy and automation level;

-Research and laboratory scenarios: used for machine vision algorithm development, image acquisition and analysis related experiments, providing stable image data acquisition support for visual technology research;

-Automated testing system: an automated testing platform integrated into various products, which achieves visual detection of the tested object through image acquisition and analysis, improving testing efficiency and accuracy.

PXIe-1435 Product imag
