Product Details Introduction

SE6000H-US000B Inverter Product Description

SE6000H-US000B is a single-phase energy storage inverter launched by SolarEdge, belonging to the Energy Hub series. It is positioned as the core component of photovoltaic energy storage systems for residential and small commercial scenarios, integrating photovoltaic energy conversion, battery energy storage management, backup power supply, and smart energy regulation functions. With HD Wave technology, it achieves high efficiency and reliability, and is widely compatible with distributed photovoltaic energy storage applications. The following is a summary of its core information:

1、 Core technical characteristics

-Efficient energy conversion: using HD Wave technology, the maximum inverter efficiency reaches 99%, CEC weighted efficiency is 98.5%, DC excess design is 200%, the maximum DC input power can reach 12000W, and the energy conversion loss is extremely low;

-Full scenario power adaptation: rated AC output power of 6000W, maximum continuous output current of 27.5A (@ 220V), total harmonic distortion<3%, power factor adjustable between -0.85 and 0.85, suitable for dual scenarios of grid parallel and backup power supply;

-Smart energy storage and backup: Supports up to 3 SolarEdge Energy Bank battery packs linked together, with a rated AC power of 6000W in backup mode (90% backup power for a single device), providing emergency power supply for the entire or partial residential area, with a backup voltage range of 194-264Vac;

-Comprehensive safety protection: integrating arc fault protection and DC fast shutdown function, in compliance with NEC 2014/2017/2020 relevant specifications; Equipped with reverse polarity protection, 600k Ω sensitivity grounding fault insulation detection, with a protection level of NEMA 4, suitable for harsh outdoor environments;

-Diversified communication and intelligent control: supports RS485, Ethernet, optional Wi Fi, and SolarEdge Energy Net communication, and can be debugged locally through SetApp mobile program; Built in billing level power generation meter (compliant with ANSI C12.20 Class 0.5 standard), supports power consumption monitoring, and can be directly connected to intelligent electric vehicle charging stations;

-Industrial grade environment adaptation: Operating temperature range of -40~+60 ℃, using natural convection cooling, operating noise<25dBA, compact size (450 × 370 × 174mm), weight only 11.8kg, supports indoor and outdoor wall installation or ceiling installation, easy installation and maintenance.

SE6000H-US000B Product imag
