0190-22543 Input/Output Module

0190-22543 Input/Output Module

Product Details Introduction

0190-22543 Input/Output Module Product Features

Integrated 16 digital inputs and 16 relay outputs, supporting dry/wet contact input and AC220V/DC24V load drive, meeting the centralized control requirements of multiple devices.

The input channel adopts optoelectronic isolation technology, with an isolation voltage of ≥ 2500VAC, which can effectively resist on-site electromagnetic interference and ensure signal acquisition accuracy.

The rated current of the output relay contact is 10A, and it supports two control modes: pulse/level. It can directly drive high-power actuators such as contactors and solenoid valves.

Compatible with Modbus RTU and Profinet dual communication protocols, achieving high-speed data transmission and remote monitoring, and adapting to industrial automation networking requirements.

Built in input signal filtering function, adjustable filtering time from 0.1ms to 10ms, suitable for high-frequency pulse signal acquisition, reducing the probability of false triggering caused by signal jitter.

Supports hot swappable design, allowing for module replacement without the need for downtime. Equipped with a redundant power supply solution, it enhances the system's continuous operation capability.

The module comes with fault diagnosis function, which can monitor channel short circuit, open circuit and overload status in real time, and provide feedback through indicator lights and messages for quick fault location.

Working temperature range -25 ℃~+70 ℃, relative humidity 10%~95%, no condensation, protection level IP30, suitable for harsh industrial site environments.

Adopting a guide rail installation structure, the installation spacing is only 25mm, which can be tightly arranged with the signal conditioning module, saving installation space for the control cabinet.

Support channel grouping control, which can divide 16 outputs into 4 independent control groups to adapt to the timing linkage requirements of different devices and improve control flexibility.

The input voltage is compatible with 12-30VDC, and the output can adapt to AC24V-240V/DC12V-60V loads, suitable for various industrial equipment power specifications.

Built in surge protection circuit, capable of withstanding ± 4kV transient surge impact, suitable for outdoor and installation scenarios near high-voltage equipment.

Support cascading with analog expansion modules, expand analog input channels, and adapt to analog signal acquisition such as pressure and temperature.

The module status can be displayed in real-time through LED indicator lights, including power, communication, channel operation, and fault status, making it easy for on-site personnel to intuitively grasp the equipment situation.

Compliant with CE and UL safety certification standards, with a full lifecycle maintenance free design and self diagnostic function, significantly reducing equipment operation and maintenance costs.

Summary: The 0190-22543 input/output module has the core advantages of high isolation, strong driving, and multi protocol compatibility. It has anti-interference, flexibility, and reliability, outstanding signal acquisition and equipment control capabilities, and can effectively improve the integration and operational stability of industrial automation systems.

0190-22543  Product imag
