Product Details Introduction

Core product features of LTE2500-TDD power module

1. Precise adaptation to the 2500MHz frequency band: The LTE2500-TDD is designed specifically for the Band41 frequency band, with a working frequency coverage of 2500-2700MHz, perfectly matching the TD-LTE 4G/5G communication system to ensure signal transmission stability.

2. Wide voltage input global compatibility: The input voltage range covers 85-264Vac, compatible with global power grid standards, supports 300Vac short-term impulse input (up to 5s), and can be deployed across regions without additional adaptation.

3. High power density compact design: With a rated output power of 88W and flat packaging technology, the size is only 239 × 268 × 58mm, leading in power density compared to products in the same frequency band, saving installation space for base stations.

4. IP67 level strict protection: It has dual protection of dust and water, excellent resistance to salt spray and corrosion, and is suitable for long-term stable operation in harsh environments such as outdoor base stations and tunnel communication.

5. Wide temperature range stable operation: The working temperature range covers -40 ℃~+70 ℃, with high temperature compensation accuracy. It maintains stable output voltage even in extreme high and low temperature environments, meeting the power supply needs of outdoor communication equipment.

6. Efficient and energy-saving operation mode: The operating efficiency at full load is over 88%, which meets the Class 2 energy efficiency standard. The no-load power consumption is as low as 0.5W, reducing the long-term operating energy consumption cost of the base station.

7. Multiple security protection system: Built in four layers of overcurrent, overvoltage, overtemperature, and short circuit protection, equipped with lightning protection circuit design, in compliance with communication equipment safety regulations, ensuring equipment and network security.

8. 3GPP standard compliance certification: Complies with 3GPP LTE security standards and EN 55032 B-class electromagnetic compatibility certification, supports AES encryption protocol, and ensures data transmission confidentiality and integrity.

9. Flexible communication interface adaptation: Integrated SMA/Fakra standard interface, supports RS485 remote monitoring, can upload power status data in real time, compatible with base station monitoring system to achieve intelligent operation and maintenance.

10. Multi scenario expansion compatibility: Supports independent operation of a single module or parallel expansion of multiple modules, adapts to various communication devices such as macro base stations, micro base stations, and IoT terminals, and is compatible with the power supply requirements of MIMO multi antenna systems.

LTE2500-TDD  Product imag

LTE2500-TDD  ontroller Module
