USAGED-03C22K servo motor

USAGED-03C22K servo motor

Product Details Introduction

Made in Japan, this classic model of Yaskawa AC servo motor has strict quality and craftsmanship guarantees.

The permanent magnet synchronous core design has an energy efficiency ratio of over 90%, low operating energy consumption, and more economical long-term use costs.

Equipped with a high-resolution incremental encoder, the positioning accuracy reaches ± 0.001mm, and the repeated positioning error is extremely small.

Fast dynamic response frequency, no delay in start stop commutation, USAGED-03C22K is suitable for high-frequency operation scenarios.

The rated torque output is stable, and the peak torque can reach three times the rated value, with strong ability to cope with instantaneous loads.

The protection level reaches IP65, dustproof and oil proof, suitable for industrial workshop environments with high dust and humidity.

Working temperature coverage -10~55 ℃, wide temperature tolerance, stable operation under harsh working conditions without pressure.

Compatible with Yaskawa servo drives of the same series, the USAGED-03C22K system does not require additional adaptation for docking.

The stator winding is made of F-grade insulation material, which has excellent voltage resistance and sufficient electrical safety guarantee.

Only 0.91kg lightweight design (approximately 2.00 lbs), high installation flexibility, and reduced equipment load.

Standardized flange installation structure, USAGED-03C22K is easy to assemble and can directly replace motors of the same specification.

Support position/speed/torque three mode control, adapt to multiple types of industrial automation scenarios.

Precise optimization of rotor dynamic balance, operating noise below 60dB, low vibration, and long service life.

Wide voltage input adaptation (AC 220V/380V optional), strong resistance to grid fluctuations.

Suitable for machine tools, robotic arms, automated conveyor lines and other equipment, with a wide range of industrial application scenarios.

USAGED-03C22K Product imag
