AS-BCTR-224 Compact Controller Module

AS-BCTR-224 Compact Controller Module

Product Details Introduction

4-channel high-speed counting channel design, with a maximum counting frequency of 25kHz, suitable for high-frequency pulse signal acquisition scenarios.

The response time is only 40 µ s (max), and the AS-BCTR-224 data processing is fast, meeting real-time control requirements.

Compatible with Modicon TSX Compact system, direct docking without additional adaptation, strong scalability.

Supports Modbus TCP communication protocol, can seamlessly link with PLC and upper computer, and has flexible networking.

24VDC rated power supply, single channel 10mA rated current, AS-BCTR-224 has low power consumption and stable power supply.

Working temperature coverage -20~70 ℃, outstanding wide temperature tolerance, suitable for extreme industrial environments.

DIN rail installation design, compact size (15 × 4 × 12cm), saving control cabinet installation space.

Input impedance of 2.5k Ω, precise signal acquisition, excellent anti-interference ability, and distortion free data transmission.

Industrial grade protective structure, AS-BCTR-224 is vibration resistant, impact resistant, and has strong operational stability.

Suitable for multiple scenarios such as material handling, packaging machinery, textile equipment, etc., with wide industrial applicability.

Support compatibility with mainstream control systems from ABB and Schneider, with convenient and unobstructed system integration.

Built in signal isolation design to avoid interference between channels and ensure reliable multi-channel synchronous operation.

Weighing only 0.16kg, the lightweight design facilitates installation and maintenance, reducing deployment costs.

Support online parameter configuration and status monitoring, intuitive and efficient troubleshooting, reducing downtime.

Original factory quality assurance, with a 1-2 year warranty and worry free after-sales service for long-term use.

AS-BCTR-224  Product imag

AS-BCTR-224 ontroller Module
