KPS-600/20-ESC power supply module

KPS-600/20-ESC power supply module

Product Details Introduction

KPS-600/20-ESC is an integrated servo power supply module designed by KUKA in Germany for robot control cabinets (such as KRC2/KRC4). It integrates the main circuit, brake control, 24V power distribution, and safety ESC logic, with three-phase 400-480V AC input, suitable for 50/60Hz power grid, providing stable and safe DC bus and control power for robot axis servo and system control. It is the core power unit of industrial robot automation system.

15 Product Features

Rated power and current: 600W power platform, 20A three-phase input rated current, intermediate circuit DC output meets multi axis servo simultaneous loading

Wide three-phase input range: 400-480V AC three-phase, 50/60Hz adaptive, suitable for mainstream industrial power grids worldwide

Integrated ESC safety logic: Built in Safety ESC safety control unit, supporting redundant monitoring of emergency stop, safety door, and axle brake chain

Full function protection system: equipped with overvoltage, undervoltage, overcurrent, short circuit, overheating, and braking resistor overheating protection, automatic fault shutdown and alarm

Integrated braking control: including shared braking for all axes of the robot and independent braking circuits for external axes, supporting fast braking and safe release

24V DC power distribution: Equipped with 24V DC voltage regulation output and distribution circuit, directly supplying to the controller I/O、 Encoder power supply

Battery backup circuit: Integrated system battery circuit to ensure that robot position data is not lost after power failure

Multi parameter real-time monitoring: can monitor the temperature of the heat sink, internal temperature, intermediate circuit voltage, and brake resistor temperature

LED status indicator: The panel indicator lights intuitively display the status of operation, standby, fault, and safety circuit, making it easy to diagnose quickly

Standard industrial interface: using screw terminals to connect the main circuit and control signals, supporting industrial buses such as EtherCAT/PROFIBUS

Compact cabinet installation: IP20 protection level, forced air cooling for heat dissipation, suitable for standard guide rail/panel installation in control cabinets

International safety certification: Passed CE, UL, RoHS certification, compliant with EN 61000, IEC 60204 industrial electrical standards

Modular design: Standardized components for easy and quick replacement of vulnerable parts such as main contactors and braking resistors, with low maintenance costs

Strong anti-interference ability: EMC optimized design, able to operate stably in strong electromagnetic industrial environments without affecting surrounding equipment

Compatible with KUKA's full range of compatible models: seamlessly integrated with KR C2/C4 controllers and various models of KR industrial robots

KPS-600/20-ESC Product imag
