KCP2-SP/00-122-429 teaching pendant

KCP2-SP/00-122-429 teaching pendant

Product Details Introduction

KCP2-SP/00-122-429 is a teaching handheld teaching device designed by KUKA specifically for the KRC2 ed05 control system. It comes standard with a 10 meter dedicated connection cable and is used for robot programming teaching, manual operation, and status monitoring. It is suitable for industrial automation training and production line debugging scenarios.

Core features of the product

Exclusive adaptability: Only compatible with KUKA KRC2 ed05 robot control cabinet, stable communication, plug and play.

Teaching optimization design: Simplify operational logic, adapt to novice programming teaching, and reduce the threshold for industrial robot training.

Complete safety protection: Integrated with a red mushroom head emergency stop button and a three-stage enable switch, in compliance with safety standards such as EN418.

Precise operation control: equipped with a six dimensional joystick, supporting precise point-to-point movement of the robot's linear movement and axis rotation.

Clear Information Display: Industrial grade LCD display screen is used to present program, coordinates, diagnosis, and status data clearly.

Convenient input layout: combination of numeric keypad and function keys, including programmable custom keys, to improve operational efficiency.

Fixed cable specifications: Comes standard with a 10 meter wear-resistant and anti torsion special cable to meet the operating radius requirements of teaching venues and workstations.

Lightweight and portable design: The body is lightweight, comfortable to hold, and suitable for long-term teaching demonstrations and practical training.

Industrial environment tolerance: The shell has dust-proof and oil proof properties, adapting to the complex environment of workshops and training centers.

Comprehensive functional coverage: supports program writing, trajectory teaching, I/O configuration, parameter setting, and system diagnosis.

Multi language support: Built in display of multiple languages such as Chinese, suitable for teaching and usage needs in different regions.

Direct power supply mode: Powered by KRC2 control cabinet through connecting cables, no additional power supply required, easy to install.

Powerful diagnostic function: Real time display of robot fault codes and operational data, facilitating teaching and troubleshooting.

Convenient program management: supports program creation, editing, saving, and import/export, meeting the needs of teaching and practical training.

Complete compliance certification: Passed CE certification and meets the requirements of low voltage, EMC, and mechanical safety related directives.

This teaching pendant is the core equipment of KUKA KRC2 system teaching and practical training, which balances operational convenience and safety reliability, providing a stable and efficient human-machine interaction tool for the cultivation of industrial robot talents.

KCP2-SP/00-122-429 Product imag
