Product Details Introduction

2711-B6C1 Operator Interface Panel Product Features

2711-B6C1 is an industrial grade color operator terminal (HMI) of the Rockwell Allen Bradley PanelView 600 series, which combines button and touch screen dual inputs and is compatible with remote I/O (RIO) networks. It is a reliable human-machine interaction interface for traditional PLC control systems, with the following core features:

Belonging to the PanelView Standard 600 product line, it supports remote I/O communication for traditional controllers such as SLC 500/PLC-5.

Color active matrix TFT display, resolution 320 × 234, display area 115 × 86mm, clear colors, suitable for industrial animation and status identification.

Dual input method: 10 physical function keys (F1-F10)+resistive touch screen (with a lifespan of 1 million presses), flexible operation.

Standard configuration includes remote I/O (RIO) master/slave ports and RS-232 printer ports, which can print alarm lists and operation reports.

The power supply is 85-264V AC wide range input (47-63Hz), compatible with global industrial power grids, and does not require additional transformers.

Memory configuration: 170KB RAM, 240KB non-volatile memory, supports ATA storage card expansion, and does not lose critical configurations and data in case of power failure.

The backlight has a lifespan of up to 50000 hours and a half at 25 ℃, and supports 2711-NL5 backlight replacement parts with low maintenance costs.

The front panel has an IP65 protection level and can be directly installed in workshops with dust and oil stains. The internal circuit is electrically isolated.

Working temperature range of 0-50 ℃, storage temperature range of -25~70 ℃, resistant to vibration and impact, suitable for harsh industrial environments.

Supporting PanelBuilder32 software programming, it can quickly create graphical interfaces, alarms, trends, formulas, and conveniently import and export labels.

Built in real-time clock (RTC) for precise timestamp recording of events and alarms.

The panel LED status indicator light intuitively displays the operating status of power, communication, faults, etc.

Standard cabinet embedded installation, stable fixing method, standardized wiring terminals, high on-site installation and debugging efficiency.

The communication protocol supports RIO and DF1, and can seamlessly integrate with mainstream Rockwell PLCs with strong compatibility.

Compliant with CE, UL, and CSA industrial certifications, with long-term stable operation, it is a mature choice for industries such as metallurgy, chemical engineering, and water treatment.

In summary, the 2711-B6C1 has the core advantages of reliable dual input, stable RIO communication, wide voltage power supply, IP65 panel, and long-life backlight, making it an ideal choice for upgrading traditional industrial control systems and achieving human-machine interaction, visual operation, and data recording.

2711-B6C1  Product imag
