TSXP575634M processor

TSXP575634M is a high-performance Unity processor for Schneider Modicon Premium platform, targeting medium to large complex industrial control systems. It emphasizes high real-time performance, strong scalability, and high reliability.

32-bit high-performance architecture, Boolean instruction execution time of 0.5 μ s (without card)/0.6 μ s (with card)

Built in 32kW RAM, supports PCMCIA expansion (64K program, 128K data)

Supports up to 16 racks and 128 slots, with a total of over 2000 I/O points

Integrated 10/100Mbps Ethernet, RS485, USB multiple communication ports

Compatible with industrial protocols such as Modbus TCP/RTU, CANopen, Uni Telway, etc

Multi task scheduling: Fast task 0.07ms, main task 1ms, ensuring real-time performance

Hardware watchdog+power outage maintenance, system stability without disconnection

7 status LEDs (RUN, I/O, ERR, TER, etc.) for intuitive operation and maintenance

5V DC power supply, typical power consumption 1680mA, low-power long-term operation

Wide temperature range of 0-55 ℃, resistant to vibration and electromagnetic interference, suitable for harsh environments

Support Unity Pro programming, IEC 61131-3 full language compatibility

Support process control loops (up to 90 simple loops)

Modular dual slot design, DIN rail installation, easy deployment

CE/UL/cUL certification, compliant with industrial safety standards

Weight 0.61kg, compact structure, suitable for dense installation of control cabinets

This processor is the core control unit of the Premium platform, widely used in large and medium-sized automation projects such as manufacturing, energy, and transportation, supporting complex logic, motion control, and data collection to the cloud.

TSXP575634M  Product imag

TSXP575634M   ontroller Module
