KJ4003X1-BE1 Vertical Right Side Expander

KJ4003X1-BE1 Vertical Right Side Expander

Product Details Introduction

KJ4003X1-BE1 is a 1-slot vertical right extender specifically designed for the Emerson DeltaV System VerticalPLUS architecture. It is used for local bus extension between controllers, power racks, and I/O racks, meeting the flexible layout requirements inside the cabinet and ensuring stable system communication and power supply.

Product Features

1 slot narrow vertical structure, dedicated to LocalBus bus extension, without installing functional modules.

Right side directional expansion design, used for right side bus connection between racks.

Adapt to VerticalPLUS local bus to ensure normal communication between controller and I/O module.

Dual power transmission ensures stable transmission of local bus power and on-site circuit power.

Has hazardous area certification and can be used in Zone 2 and Class I Div 2 hazardous areas.

The working temperature ranges from -40 ℃ to+70 ℃, suitable for harsh industrial site environments.

Strong anti vibration and anti impact performance, suitable for long-term operation in industrial sites.

Supports non condensing humidity environments ranging from 5% to 95%, with an IP20 protection level.

Compliant with ISA-S7.1.04 G3 anti-corrosion grade, resistant to dust and oil erosion.

After being combined with the bracket, the total length of the bus shall not exceed 6.5 meters to ensure signal stability.

Power off operation is required, and live plugging and unplugging are strictly prohibited.

Cross cabinet connections can be made using conduit wiring to reduce interference and physical damage.

Standard T-shaped DIN rail installation, compatible with various standard industrial control cabinets.

No user repairable parts, stable structure, maintenance free calibration.

Compact size, easy to flexibly arrange inside the cabinet, optimizing space utilization.

ending

KJ4003X1-BE1 is a key component of the DeltaV system that enables flexible expansion within cabinets. It has high reliability and strong environmental adaptability, and is widely used in industries such as petrochemicals, power, and coal chemical. Installation and use must strictly comply with system hardware specifications to ensure safe and stable operation of the system.

KJ4003X1-BE1 Product imag
