KJ4001X1-NA1 Dual Right Expander Module

KJ4001X1-NA1 Dual Right Expander Module

Product Details Introduction

KJ4001X1-NA1 is a horizontal local bus dual right cable extender specifically designed for Emerson DeltaV systems. It is used to extend system local bus connections, expand I/O module layouts, and enhance system configuration flexibility. Its specific features are as follows:

Belonging to the LocalBus extension component of DeltaV system, model 12P3373X012, designed for dual right direction extension.

Extend the local bus cable, support the expansion of the right-hand dual I/O module group, and adapt to high-density I/O configuration requirements.

Provide 12 VDC, 8A local bus power supply to ensure stable power supply for expansion modules.

Equipped with Class I Div 2 and Zone 2 explosion-proof certifications, meeting safety standards such as ATEX and IECEx.

Wide temperature working range -40 ℃ to+60 ℃, suitable for extreme temperature environments in industrial sites.

The mechanical structure is sturdy, with strong resistance to vibration and impact, meeting the requirements of continuous production conditions.

Suitable for high humidity and non condensing environments, compatible with harsh air conditions in industrial sites.

Standard rail installation, compact structure, light weight (about 0.18kg), convenient for flexible layout inside the cabinet.

Seamless integration with DeltaV control system ensures stable and delay free bus communication.

Support applications in hazardous areas to meet the safety deployment requirements of process industries such as chemical, oil and gas.

Maintenance free and calibration free design, reducing system operation and maintenance costs and downtime.

Built in bus signal conditioning enhances signal integrity and anti-interference capability for long-distance transmission.

It does not support live plugging and unplugging, and requires power-off operation to ensure on-site installation and maintenance safety.

Global universal security certification, suitable for cross-border industrial automation project deployment.

As a key component for system expansion, it helps to achieve a distributed and modular architecture for large-scale control systems.

Summary: KJ4001X1-NA1 is the core module for implementing local bus expansion in DeltaV system, with dual expansion, stable power supply, explosion-proof safety, and wide temperature adaptation as its core advantages. It is widely used in process industries such as chemical, oil and gas, and power that require long-distance and high-density I/O layout.

KJ4001X1-NA1 Product imag
