Product Details Introduction

Introduction to KJ3005X1-BA1 Sensor Module

Product positioning

KJ3005X1-BA1 is a sensor input/interface module for process automation systems, used to read analog signals from various on-site sensors and convert them into digital data that can be processed by the control system.

core functionality

Receive analog signals from on-site sensors (such as 4-20 mA, 0-10 V, etc.)

Convert and sample analog signals

Transfer the collected sensor data to the control system

Supports multiple sensor types (depending on module design)

main purpose

Collection of on-site process variables such as temperature, pressure, and liquid level

Connect with the control system to achieve monitoring and feedback of the production process

Closed loop regulation for process control systems

As an interface for on-site measurement signals to enter the control system

Performance Characteristics

Multi channel input design improves on-site measurement efficiency

Good anti-interference ability, suitable for industrial site environment

High compatibility with process control systems

Modular structure, easy to replace and maintain

Installation and Usage

This module is usually installed on the I/O rack or motherboard of the control system, and requires parameter settings and channel configuration in the control system to collect and upload on-site sensor data normally. The module itself does not contain control logic and is only responsible for signal acquisition and transmission.

summary

KJ3005X1-BA1 sensor module is a module responsible for collecting on-site sensor signals in automation control systems. By converting analog signals into digital data, it achieves real-time monitoring of on-site variables and data input for control systems.

KJ3005X1-BA1  Product imag
