KJ3002X1-BD1 Analysis Input Module

KJ3002X1-BD1 Analysis Input Module

Product Details Introduction

The KJ3002X1-BD1 analysis input module is a module used in industrial automation systems to collect and process output signals from on-site analytical instruments, specifically designed for continuous process control and online analysis monitoring. It is commonly used in DeltaV systems to process analog signals and provide high-precision data to controllers or logic processing units.

1、 Product positioning

This module belongs to the analog/analytical signal input unit, mainly aimed at online analytical instruments in industries such as chemical, petroleum, and environmental protection, such as pH, conductivity, redox potential, and other sensor outputs. It converts these continuously changing signals into digital information for closed-loop control or data recording by the control system.

2、 Core functions

Analyze signal acquisition

Support multiple on-site analysis instrument signals, including voltage, current, four wire system, or special sensor outputs.

High precision signal processing

The module provides signal filtering, amplification, and digital conversion to ensure data stability and accuracy.

Electrical isolation

Provide isolation between channels and between channels and the control system power supply to prevent interference and system fault propagation.

Status monitoring and alarm

Can detect open circuits, short circuits, sensor faults, and issue abnormal alerts to the system.

modular installation

Supports standard rack or DIN rail installation for easy system expansion and maintenance.

3、 Technical features

High resolution analog input ensures measurement accuracy

Multi channel input design, supporting centralized data collection

Industrial grade wide temperature design, resistant to high temperature, humidity, and vibration

Strong ability to resist electromagnetic interference

Suitable for continuous long-term operation

KJ3002X1-BD1 Product imag
