KJ2101X1-CA1 Migration Controller Card

KJ2101X1-CA1 Migration Controller Card

Product Details Introduction

KJ2101X1-CA1 is a migration controller card in Emerson DeltaV distributed control systems, used as the control core unit during system upgrades or migrations, while managing on-site I/O signals and system network communication.

1、 Module positioning

Installed in the control slot of the DeltaV cabinet, used as a control node.

Execute control strategies, process I/O data, and communicate with the system's main network.

'Migration' means it is commonly used during the upgrade or transition of old systems to the DeltaV platform to ensure smooth migration of control logic.

2、 Main functions

Control execution

Implement PID regulation, sequential logic, and process control strategies.

I/O Data Management

Interact with the on-site I/O subsystem, read status signals, and output control instructions.

System network communication

Communicate with other controllers, interface modules, and monitoring/engineering stations to ensure smooth data transmission in the distributed control system.

modular design

Can be plugged into the DeltaV control backplane, with bus integration for easy system expansion and maintenance.

3、 Application scenarios

During system upgrade or migration, replace old control units.

Execute logic as a control node in a distributed DeltaV system.

Coordinate data exchange between on-site I/O and controllers.

Ensure the continuity and reliability of the control strategy during the transition period.

KJ2101X1-CA1 Product imag
