KJ1710X1-BA1 single port fiber switch

KJ1710X1-BA1 single port fiber switch

Product Details Introduction

KJ1710X1-BA1 is a single port fiber optic switch in Emerson DeltaV distributed control systems, used as an interface and bridge for fiber optic communication in industrial control networks. It is mainly used to connect control networks with fiber optic links, improving communication distance and anti-interference capabilities.

1、 Module positioning

Used in DeltaV systems to connect fiber optic links to control network interfaces.

Suitable for remote cabinets or control nodes, ensuring stable data transmission between controllers and I/O modules.

Belonging to the network infrastructure module of the control system, it does not directly participate in the control logic.

2、 Main functions

Single port fiber optic connection

Provide a fiber optic port to establish communication links with other fiber optic devices, improving the stability of long-distance data transmission.

Internet Bridge

Implement physical layer bridging between fiber optic and Ethernet control networks to enable collaborative communication among control system nodes.

Industrial grade reliability

The module is suitable for industrial environments with a wide temperature range, vibration resistance, and impact resistance, ensuring long-term stable operation on site.

3、 Typical technical features

Working voltage: DC power supply (approximately 19-28V DC)

Working current: approximately 250 mA DC

Temperature range: -40 ° C to+70 ° C

Installation method: Cabinet or rail installation

Anti vibration and anti impact capability: meets industrial grade standards

4、 Application scenarios

Fiber optic communication between control station and remote nodes

Network topology bridging across cabinets or remote field nodes

Data transmission in high interference and complex electromagnetic environments

Improving the reliability of distributed control system networks

KJ1710X1-BA1 Product imag

KJ1710X1-BA1 ontroller Module
