Product Details Introduction

KJ1502X1-BA2 is a control/interface module in Emerson DeltaV distributed control system (DCS), used to execute control logic in the system network and communicate with other controllers, I/O modules, and monitoring devices. It is one of the core control node units in the DeltaV system.

1、 Module positioning

This module is installed in the control slot of the DeltaV cabinet and is responsible for:

Control strategy execution

Data exchange with I/O subsystem and other control nodes

System monitoring and status feedback

It is both a controller and a network interface unit, ensuring the coordinated operation of the entire control system.

2、 Main functions

Control execution

It can execute control strategies such as PID regulation, sequential logic, and logical judgment.

network communication

Exchange data and status with other controllers, I/O units, and monitoring/engineering stations in the system to ensure coordinated operation of the control network.

system integration

Centralized management can be achieved through the DeltaV engineering tool for unified configuration, debugging, and diagnosis.

Redundancy and hot plugging

Support redundant switching between primary and backup controllers, hot swappable during system operation to improve availability.

3、 Typical applications

Execution of process control strategy

I/O subsystem data coordination

Redundant architecture of multi controller system

Engineering and monitoring data exchange

KJ1502X1-BA2 Product imag

KJ1502X1-BA2 ontroller Module
