Product Details Introduction

Introduction to IC697VAL134 Analog Input/Output Module

IC697VAL134 is an analog input/output interface module in GE Fanuc 90-70 series PLC systems, used to collect on-site analog signals and output control signals, expanding the system's ability to process analog signals. It is not a PLC main controller, but an I/O module installed in the PLC rack and used in conjunction with the CPU.

1、 Module function positioning

Type: Analog input/output interface module

Series: 90-70 series PLC

Function:

Collect simulated signals from on-site sensors

Support outputting analog control signals

Direct connection between communication and CPU backplane bus

2、 Main technical specifications

Input channel:

Multiple analog input channels for receiving on-site analog voltage/current signals

Support common industrial current signals (such as 4-20mA) or voltage signals

Output channel:

If output is supported, standard analog control signals can be output to actuators or control devices

Resolution: 12 bit or higher A/D and D/A conversion accuracy

Isolation performance: Input/output is isolated from the backplane, enhancing anti-interference ability

Backboard power supply: The required current is provided by the PLC backplane power supply

3、 Typical use

IC697VAL134 is commonly used in the following scenarios:

Read and process analog sensor signals such as temperature, pressure, and flow rate

Output the control results of the PLC CPU as standard analog voltage/current

Monitoring continuous process variables

Analog input terminals for controlling devices such as frequency converters and electric valves

IC697VAL134 Product imag
