IC697VAL132 controller module

IC697VAL132 controller module

Product Details Introduction

IC697VAL132 Controller Module Description

IC697VAL132 is an analog input module in GE Fanuc 90-70 series PLC systems, used to collect and convert on-site analog signals into digital signals for PLC CPU processing. It is not an independent programmable controller, but a module used to expand the input functions of PLC systems.

1、 Module function and positioning

Module type: Analog input module

Series: 90-70 PLC

Function: Convert the current signal output by the on-site sensor into a digital signal and transmit it to the PLC CPU

Applicable scenario: In industrial process control, it is necessary to read analog signals

2、 Main technical specifications

Input channel:

Supports multiple differential inputs or single ended inputs

The input type is current signal (such as 0~20mA, 4~20mA, 5~25mA)

Resolution: 12 bit A/D conversion

Isolation performance: Input and backplane isolation to improve anti-interference ability

Power supply method: 5V DC power is provided from the PLC backplane

Installation method: Insert into the I/O slot of the PLC rack and communicate with the CPU through the backplane

Compatibility: Suitable for 90-70 series PLC systems, partially compatible with PACSystems systems

3、 Application Fields

Read analog variables such as pressure, flow rate, temperature, etc

Industrial process data collection and monitoring

In situations where analog inputs are required in PLC control logic

Automated production line and process control system

IC697VAL132 Product imag

IC697VAL132 ontroller Module
