IC697PWR710 power supply module

IC697PWR710 is the standard power module for GE Fanuc 90-70 series PLC systems, responsible for providing stable DC power to the entire rack, supporting the normal operation of CPU, I/O modules, and expansion modules.

1、 Main functions

Provide stable power supply

Output+5V DC to power the 90-70 system backplane and modules, ensuring stable operation of the PLC.

Installation location

It must be installed in the leftmost slot of the rack, forming a complete system with the CPU and I/O modules.

protection function

Built in overvoltage and overcurrent protection, as well as electronic current limiting, enhance system safety.

Short term maintenance during power outage

It can maintain short-term output when communication input is interrupted instantly, reducing the impact of instantaneous power failure on the system.

2、 Technical features

Input voltage range

AC：90–264 VAC，47–63 Hz

DC：100–150 VDC

output parameters

Nominal+5.1 V DC, allowable range approximately 4.9-5.25 V

The maximum output current is about 11 A

The maximum output power is about 56   W

Industrial-grade design

Strong stability, adaptable to complex industrial environments, and good anti-interference ability.

Modular structure

Plug in design, convenient for on-site installation and maintenance.

3、 Application scenarios

Factory Automation and Process Control System

Manufacturing site PLC control system

Industrial environments that require wide input voltage support and short-term power outage protection

summary

IC697PWR710 is the core power module of the 90-70 PLC system, providing stable+5V DC power supply and basic protection functions for the system. It is the foundation for the stable and reliable operation of the entire PLC system, suitable for various industrial automation scenarios

IC697PWR710  Product imag
