NASM02 Analog Input Module

NASM02 Analog Input Module

Product Details Introduction

NASM02 Analog Input Module Product Features (15)

1. ABB Bailey original analog input module, equivalent to IMASM02 model, suitable for Infi 90 system exclusive scenarios.

2. Focus on thermocouple (TC) and millivolt (Mv) signal acquisition, accurately adapting to temperature sensing scenarios.

3. Exclusive 8-channel signal input channel, designed specifically for low-level millivolt signals, with better acquisition sensitivity than general modules.

4. Compatible with mainstream thermocouple models such as K, J, T, etc., and can directly interface with high and low temperature detection sensors.

5. Built in signal amplification module, effectively improving the identification of weak signals at the millivolt level and reducing distortion rate.

6. It needs to be used in conjunction with auxiliary modules such as INBIM02 and NTCL01 to achieve complete system linkage control.

7. Adopting differential input design, the common mode rejection ratio is superior to others, accurately shielding industrial field level interference.

8. Independent electrical isolation between channels to avoid single channel faults affecting the overall stability of module operation.

9. Compatible with industrial standard 24V DC power supply, with reverse connection protection to prevent module damage caused by wiring errors.

10. The working temperature covers -40 ℃ to 70 ℃, and can withstand high humidity without condensation environment, suitable for extreme working conditions.

11. Modular plug-in structure, compatible with standard DIN rail installation, easy and efficient maintenance and replacement.

12. Built in thermocouple cold junction compensation function ensures temperature measurement accuracy without the need for additional accessories.

13. Support fault self diagnosis and provide real-time feedback on channel signal abnormalities, module communication interruptions, and other issues.

14. Seamless adaptation with ABB Bailey NTMP01 terminal unit to optimize signal transmission link stability.

15. The PCB board is treated with anti-oxidation technology to extend its service life in industrial corrosive environments.

16. Widely used for monitoring high-temperature furnace bodies in metallurgy and chemical industry, accurately capturing temperature dynamic change data.

NASM02 Product imag

NASM02 ontroller Module
