DAM-14 alarm device

DAM-14 alarm device

Product Details Introduction

Product Features of DAM-14 Alarm Device

1. Dual parameter monitoring and warning: Supports synchronous monitoring of residual current and temperature dual parameters, and can set warning and alarm values separately to achieve early fault prediction and reduce false triggering.

2. Wide range precise adjustment: residual current monitoring range is 50mA-999mA, temperature alarm range is 25-125 ℃, accuracy error is ± 5%, meeting the protection needs of different scenarios.

3. Multi level alarm protection: It has a three-level protection mechanism of warning, alarm, and trip. The protection action can be freely switched between "enable/disable", and the response time is as fast as 0.5 seconds.

4. Sound and light synchronous alarm: Built in high decibel sound device, alarm volume ≥ 70dB, equipped with eye-catching LED warning lights, can quickly transmit alarm signals in complex environments.

5. Fire linkage compatibility: Supports DC24V (12-24V) fire linkage input, which can be linked with external devices such as solenoid valves and exhaust fans to automatically eliminate safety hazards.

6. Stable communication transmission: Using CAN bus communication method, signal transmission distance ≤ 1km, strong anti-interference ability, can be connected to the upper computer for centralized control.

7. Convenient operation display: Equipped with a touch sensitive keyboard and digital display panel, monitoring data and alarm status can be viewed intuitively, and parameter settings are simple and easy to understand.

8. Flexible installation and adaptation: Supports DIN rail installation, easy wiring and pre wiring, suitable for various places such as industrial plants and building distribution rooms.

9. Endurance to harsh environments: Operating temperature range of -20 ℃ -+40 ℃, relative humidity of 10% -90%, no condensation, altitude ≤ 2000m, reliable protective performance.

10. Safety performance guarantee: Equipped with fault self checking function, it can promptly provide feedback on abnormal equipment operation, with a contact capacity of 250VAC/3A and stable alarm tripping output.

DAM-14 Product imag

DAM-14 ontroller Module
