PCI-6220 Data Acquisition Card

PCI-6220 Data Acquisition Card

Product Details Introduction

PCI-6220 Data Acquisition Card Product Features

6. Integrated digital I/O functionality

Provide 24 bidirectional TTL/CMOS level digital channels, support programmable power on status, and meet the requirements of switch control and monitoring.

7. Dual 32-bit counter/timer

Built in 2 32-bit universal counters, supporting frequency measurement, pulse generation, encoder input and other functions, with a time base stability of 50 ppm.

8. Rich triggering and timing modes

Supporting multiple triggering methods including software, external, and digital, equipped with a 1 MHz clock rate, it can achieve event driven data collection and improve system response efficiency.

9. Strengthen anti-interference design

By using shielding and filtering techniques, the input impedance is greater than 1 G Ω, effectively resisting industrial electromagnetic interference and ensuring signal acquisition stability in complex environments.

10. Adaptation to a wide temperature working environment

The working temperature range is from 0 ℃ to 55 ℃, and the storage temperature can reach -20 ℃ to 85 ℃. It can operate stably in various industrial and laboratory scenarios.

11. Multi system software compatibility

Supports Windows, Linux, Mac OS, and real-time systems, compatible with various development environments such as LabVIEW, MATLAB, C/C++, and comes with NI DAQmx drivers.

12. Standard PCI interface adaptation

Adopting a 32-bit 5V PCI 2.2 compatible interface, connected through a 68 pin VHDCI female connector, card type installation, compatible with mainstream industrial control computers.

13. Rich signal conditioning options

It supports more than 70 types of signal conditioning accessories, which can be optimized for different sensor signals, expanding the product's application range and measurement accuracy.

14. Compliant with RoHS compliance standards

The product meets the requirements of RoHS directive, meets environmental standards, and is suitable for various industrial and scientific research application scenarios with strict compliance.

PCI-6220  Product imag
