810-282987-001 interface board module

810-282987-001 interface board module

Product Details Introduction

810-282987-001 Interface Board Module Product Application Fields

The 810-282987-001 interface board module, as an industrial grade high reliability signal conversion and communication core unit, adopts a multi-channel electrical isolation design, integrates rich digital/analog interfaces and communication interfaces such as RS-232/RS-485, supports mainstream industrial protocols such as Modbus, and has excellent anti electromagnetic interference performance and wide temperature adaptability. It can achieve precise signal matching, high-speed data exchange, and protocol conversion between control systems and field devices, and can withstand harsh working conditions such as voltage fluctuations, dust, and vibration in industrial sites. It is a key "bridge" connecting central control units and terminal devices, widely used in industrial automation, energy and power, chemical metallurgy and other fields. The core application scenarios are as follows:

1. In the field of industrial automation control, it is suitable for industrial control core equipment such as PLC (Programmable Logic Controller), frequency converter, servo system, etc., providing stable DC power supply to ensure the continuous and accurate operation of automated production lines, intelligent warehousing equipment, industrial robots and other systems. It can withstand complex environments such as voltage fluctuations and electromagnetic interference in industrial sites. 1. In the field of industrial automation and DCS system integration, it is suitable for the interconnection between distributed control systems (DCS), PLC systems, and field equipment, serving as a signal transfer core to achieve signal matching and isolation transmission between sensors, actuators, and main controllers. Support multi-channel parallel data processing, effectively block ground loop interference and electromagnetic interference, ensure the accuracy of temperature, pressure, flow and other parameter acquisition in automated production lines and smart factories, simplify system wiring and integration debugging processes.

2. In the field of energy and power monitoring: applied to monitoring systems for thermal power generation, photovoltaic power stations, and substations, achieving communication and interconnection between DCS main controllers and booster station protection devices, energy meters, sensors, and other equipment. By using protocol conversion function to ensure seamless data exchange between devices from different manufacturers, real-time collection of power parameters and equipment operating status is achieved, with high resistance to electromagnetic interference, ensuring stable and reliable monitoring data for energy production and transmission processes.

3. In the field of chemical engineering and oil and gas storage and transportation: used for process control systems in petroleum refining equipment and long-distance oil and gas pipelines, responsible for signal transfer tasks between controllers and third-party analyzers, safety instrumented systems (SIS), valve positioners, and other equipment. Compliant with industrial safety protection requirements, capable of stable operation in flammable, explosive, and high humidity environments, ensuring the reliability of process parameter monitoring and safety interlock control through signal isolation and precise transmission.

4. Metallurgy and intelligent manufacturing field: Suitable for blast furnace and converter monitoring systems of metallurgical production lines, as well as electrical control systems of machine tool equipment, to achieve accurate acquisition and transmission of analog signals such as temperature, pressure, displacement, and reliable issuance of control instructions. Supporting high-speed signal processing and filtering functions, it can effectively suppress the influence of strong electromagnetic interference and vibration in the workshop on signals, ensuring the stability of metallurgical production and precision machining.

810-282987-001 Product imag
