Product Details Introduction

X7-3P3P1L1L12 Power Supply Module Product Overview and Application Fields

The X7-3P3P1L1L-12 power supply module is an industrial modular power supply unit with high reliability and flexible scalability. It adopts a wide range AC input design and active power factor correction (PFC) technology, with high conversion efficiency and low ripple noise. It supports precise adjustment and remote control of output voltage, integrates multiple protection mechanisms such as overvoltage, overload, short circuit, and overheating, and has excellent resistance to impact and electromagnetic interference. It can adapt to industrial environments with a wide temperature range of -20~+70 ℃. This module supports parallel/series configuration to expand power, equipped with AC OK, DC OK and other status signals, and can provide continuous and stable power supply support for various industrial electronic devices. The core applications are as follows:

1、 In the field of industrial automation and intelligent manufacturing

Core scenario: Provide stable DC power supply for PLC controllers, servo drives, distributed I/O modules, and industrial sensor networks, ensuring precise transmission of control signals with low ripple characteristics; The control cabinet system adapted for automated production lines has a wide voltage input characteristic that can cope with power grid fluctuations, and supports 150% rated current short-term overload to adapt to motor and solenoid valve start-up shocks; Through remote on/off and status monitoring functions, real-time control of power operation status is achieved, facilitating production line operation and fault diagnosis, and adapting to high-end manufacturing scenarios such as automotive manufacturing and electronic processing.

2、 In the field of communication and network infrastructure

Core scenario: As an auxiliary power supply unit for communication base stations and data centers, it provides stable power supply for routers, switches, and network monitoring equipment, with low no-load power consumption characteristics to reduce energy loss; Adapting to unmanned communication stations, with wide temperature operation and high reliability design, ensuring continuous operation of communication equipment 7 × 24 hours in harsh outdoor environments; Support linkage with UPS system to achieve seamless power switching in case of grid interruption, ensuring the continuity of network data transmission.

3、 In the field of new energy and power electronics

Core scenario: Applied to control units of photovoltaic inverters and energy storage systems, providing reliable power for battery management systems (BMS) and monitoring modules, adapting to outdoor high and low temperature environmental fluctuations; Adapt to the communication and sensor power supply of wind power control system, with strong anti electromagnetic interference capability to ensure stable data transmission; The relay protection device and remote terminal unit (RTU) used for intelligent substations are powered by high voltage stability accuracy to ensure accurate execution of power dispatch instructions.

4、 Special instruments and rail transit field

Core scenario: Provide high-precision power supply for industrial testing instruments and precision analysis equipment, with low ripple noise to ensure the accuracy of testing data; Adapt to on-board electronic equipment of rail transit, withstand strong vibrations and high and low temperature cycles, and provide stable power supply for on-board communication, positioning, and safety monitoring systems; Used as an auxiliary power supply for medical diagnostic equipment (such as monitors and analyzers), it meets industrial safety certification standards, has safety isolation characteristics, and ensures the safe operation of equipment and patient safety.

X7-3P3P1L1L-12 Product imag
