Product Details Introduction

HGD-3000 Hydrogen Smoke Temperature Multi Parameter Detector Product Description

Note: The HGD-3000 is not simply a temperature detector, but a multi parameter safety monitoring device that integrates hydrogen detection, smoke detection, temperature monitoring, and optional intrusion alarm functions (mainstream models are products under Eagle Eye Power Solutions). Its core positioning is security protection for unmanned battery rooms, remote computer rooms, and other scenarios, and it can achieve 24-hour continuous monitoring and automatic emergency response. The following is a summary of its core information:

1、 Core technical characteristics

-Multi parameter integrated monitoring: equipped with high-sensitivity solid-state hydrogen sensors, photoelectric smoke sensors, and built-in thermostats, it can simultaneously monitor the three core safety parameters of hydrogen concentration, smoke, and ambient temperature. It also supports optional infrared intrusion monitoring function;

-Accurate response and graded linkage: When the hydrogen concentration reaches 1%, the exhaust fan will automatically start, and when it reaches 2% (below the lower explosive limit of 4.1% hydrogen), an alarm will be triggered; When the temperature exceeds the preset threshold (default 40 ℃, adjustable range ± 5 ℃), automatic exhaust cooling will be activated. When smoke detects combustion products, an independent alarm will be triggered immediately and exhaust will be prohibited (to prevent oxygen supply and combustion assistance);

-Multi dimensional alarm mechanism: equipped with an 80dB local buzzer, red flashing LED indicator light, and a dry contact switch, which can achieve remote alarm linkage and trigger dry contact alarm even in power failure state;

-Industrial grade adaptability: Operating temperature range of -10~40 ℃ (14~104 ° F), in compliance with multiple industry standards such as NFPA 2 and IEEE 450, suitable for Class B hazardous environments in Zone 1 and Group 2; Supports 85-265VAC (50/60Hz) or 17-60VDC wide voltage power supply, with a small size (178 × 120 × 55mm), and can be wall mounted, ceiling mounted, or installed through junction boxes.

2、 Core application areas

-Power energy scenario: suitable for UPS power system rooms, lead-acid battery charging rooms, fuel cell testing stations, auxiliary rooms of hydropower/thermal power stations, to prevent hydrogen accumulation and electrical fire risks caused by battery charging;

-Communication and Public Utilities: Adapt to remote data centers for telecommunications base stations and remote shelters for public utilities, ensuring equipment safety and environmental stability in unmanned scenarios;

-Special energy scenarios: can be used in hydrogen containing environments such as hydrogen fuel injection stations and nuclear waste reforming facilities to achieve early warning of hydrogen leakage and fire hazards;

-Other industrial scenarios: Suitable for power battery storage areas such as golf carts, industrial energy storage battery compartments, etc., providing comprehensive safety monitoring and protection.

HGD-3000 Product imag

HGD-3000 ontroller Module
