A860-2020-T301 Encoder

A860-2020-T301 Encoder

Product Details Introduction

1、 Core positioning

FANUC's original absolute servo motor encoder is designed specifically for precision motion control. Its core function is to convert mechanical motion into electrical signals, achieving precise monitoring of position and speed

Brand: FANUC, Suitable for FANUC β iA128 series servo motors

Product status: Both brand new original and refurbished parts are available, third-party channels provide in stock, and some support warranty services

2、 Key parameters

Accuracy and Signal: Resolution up to 25 bits (approximately 33 million pulses per revolution), supporting 90 ° anti phase 2-bit output waveform, 3-channel model with 1 pulse per revolution output

Communication and Interface: Supports S7 bus protocol, RS-422 protocol, 17 core aviation plug connection, incremental/absolute dual-mode output

Power supply and environment: DC5V ± 5% power supply (TTL compatible output), operating temperature -25 ℃ to 85 ℃ (some versions can withstand -40 ℃~100 ℃), protection level IP67

Physics and Performance: Compact in size (reference size Φ 58mm × 85mm), weighing approximately 0.35kg, with a vibration resistance level of 10G (10-2000Hz), and a signal refresh rate of up to 500kHz

3、 Core functions and applications

Core function: After power failure, there is no need to reinitialize, and the current position can be directly reported; Strong anti-interference ability, with a linear error of only ± 0.005% (full range)

Application scenarios: CNC machine tools (milling, turning, drilling), industrial robots, woodworking machinery, textile machinery, medical equipment, carving machines and other precision equipment

A860-2020-T301 Product imag
