Product Details Introduction

SGMDH-12A2A-YR with a rated power of 1150W has strong power output and is suitable for medium power load scenarios.

The nominal torque reaches 5.49Nm, and the instantaneous maximum torque performance is excellent. SGMDH-12A2A-YR can handle instantaneous loads without pressure.

Equipped with a 17 bit high-resolution serial encoder, SGMDH-12A2A-YR has high positioning accuracy and stable feedback signals.

The standard built-in DC90V holding brake, SGMDH-12A2A-YR has sufficient braking torque, and there is no slip when stopping.

The protection level reaches IP67, and SGMDH-12A2A-YR can resist dust and deep water splashes, making it suitable for harsh industrial environments.

The rated speed is 2000rpm, and the maximum can reach 3000rpm. SGMDH-12A2A-YR has stable high-speed operation performance.

Flat structure design, flexible installation of SGMDH-12A2A-YR, saving equipment layout space.

Adopting permanent magnet excitation method, SGMDH-12A2A-YR has outstanding energy efficiency and reasonable energy consumption control.

Compatible with SGDM/SGDH series servo drives, SGMDH-12A2A-YR system is easy to connect.

The insulation level reaches F level, the withstand voltage is AC1500V/1 minute, and SGMDH-12A2A-YR has high electrical safety.

The working temperature range is 0-40 ℃, and SGMDH-12A2A-YR is suitable for industrial scenarios in multiple temperature zones.

Flange installation design, SGMDH-12A2A-YR is easy to assemble and has strong connection stability.

The vibration level reaches V15, and SGMDH-12A2A-YR runs smoothly with excellent noise control.

Fully enclosed self cooling design, SGMDH-12A2A-YR does not require additional heat dissipation and has low maintenance costs.

SGMDH-12A2A-YR is suitable for multiple equipment such as robotic arms and food processing machinery, and has a wide range of application scenarios.

SGMDH-12A2A-YR  Product imag
