Product Details Introduction

IDF-06 (IDF06M-00320) is equipped with a 3.5-inch TFT color touch screen with a resolution of 320 × 240, providing clear and intuitive display. It supports bilingual switching between Chinese and English and has a low operating threshold

Deeply compatible with PLCs, servo drives, and industrial sensors, supporting mainstream communication protocols such as Modbus RTU/TCP, Profinet, etc., with a data transmission delay of ≤ 2ms and rapid linkage response

Supports dual methods of embedded installation and wall mounted fixation, with thin panel thickness and small space occupation, suitable for various industrial control cabinets and equipment operation surface layouts

IDF-06 (IDF06M-00320) has a protection level of IP65, and the front panel is dustproof, waterproof, and splash proof. It can be directly deployed in multi dust working conditions such as mechanical processing and automated production lines

Built in 32-bit high-performance processor, supports 128 custom control logic programming, and can flexibly adapt to different process parameter settings and process control requirements

Working temperature coverage -10 ℃~+60 ℃, humidity tolerance 10%~90% (no condensation), equipped with anti glare screen design, can still be clearly viewed in strong light environments

IDF-06 (IDF06M-00320) is equipped with 8 programmable digital input/output interfaces, supporting passive contact and NPN/PNP signal access, and is compatible with multiple types of sensor linkage

Equipped with parameter password protection and operation log recording function, it can trace key operation processes, prevent system abnormalities caused by misoperation, and enhance control security

Supporting remote monitoring and parameter modification, remote operation and maintenance can be achieved through Ethernet interface without on-site duty, reducing maintenance and time costs

IDF-06 (IDF06M-00320) adopts a silicone sealed button and touch dual operation mode, with a button life of over 1 million times, wear-resistant and comfortable to handle

Compatible with Windows/Linux system upper computer software, supporting parameter backup, batch copying, and firmware upgrade, convenient and efficient debugging and system updates

Built in overvoltage, overcurrent, and electrostatic protection mechanisms, interface circuit with electrical isolation design, strong electromagnetic interference resistance, suitable for complex industrial electromagnetic environments

IDF-06 (IDF06M-00320) is widely used in CNC machine tools, packaging machinery, assembly line control, energy monitoring and other scenarios, adapting to the operational needs of multiple industries

  IDF-06 (IDF06M-00320) Control Panel Product imag
