MDFKARS090-22 servo motor

 MDFKARS090-22 servo motor

Product Details Introduction

MDFKARS090-22 adopts a permanent magnet synchronous design, with a rated power of 0.75kW, a rated torque of 2.4N · m, and a rated speed of 3000rpm, suitable for medium power precision drive scenarios

Equipped with a 2500p/r high-resolution encoder, the positioning accuracy reaches ± 0.01 °, and closed-loop control ensures the consistency of equipment trajectory control and repeated positioning accuracy

Suitable for three-phase AC 220V standard power supply, with a voltage fluctuation tolerance of ± 10%, to cope with industrial power grid fluctuations, and has wide adaptability to different regions and scenarios

MDFKARS090-22 has a protection level of IP65 and a metal sealed shell that is dustproof, waterproof, and splash proof. It can be directly deployed in multi dust working conditions such as mechanical processing and automated production lines

Compatible with mainstream industrial communication protocols such as Modbus and EtherCAT, it responds quickly in conjunction with PLCs and servo drives, with a data transmission delay of ≤ 1ms

Working temperature coverage -10 ℃~60 ℃, humidity tolerance ≤ 90% (no condensation), equipped with F-class insulation design, suitable for high and low temperature fluctuation industrial environment

MDFKARS090-22 has the ability to withstand 150% rated torque overload for 60 seconds, with built-in multiple protections for overcurrent, overheating, and locked rotor, ensuring the safety of the motor and load

Smooth and vibration free low-speed operation, torque fluctuation of ≤± 5%, meeting high-precision process requirements such as low-speed feed and precision positioning for CNC machine tools

Support position/speed/torque three mode switching, which can be freely configured through parameters to adapt to different process control requirements

The MDFKARS090-22 body is made of high-strength aluminum alloy material, which is lightweight and has excellent heat dissipation performance. The continuous operating temperature rise is ≤ 80K, extending the service life

Standard flange installation design, suitable for installation layout of various automation equipment, matched with tapered spline shaft, firmly connected, high transmission accuracy

Built in electromagnetic braking function, braking response time ≤ 20ms, quickly locks the axle after power failure to prevent load sliding and improve operational safety

MDFKARS090-22 is widely used in precision manufacturing equipment such as CNC milling machines, machining centers, automated robotic arms, packaging machinery, etc

Deeply compatible with mainstream servo drives, no additional adaptation module required, low integration cost, convenient and efficient debugging

Using standardized installation dimensions and wiring interfaces, there is no need to modify the mechanical structure and wiring when replacing old and new equipment, reducing downtime for maintenance

 MDFKARS090-22 servo motor Product imag
