ICD890-00000000 Image Acquisition Device

 ICD890-00000000 Image Acquisition Device

Product Details Introduction

ICD890-000000 is equipped with 8192 pixel high-definition photosensitive components, supporting 200-250DPI image output, accurately capturing barcode, text, and object features, meeting the needs of OCR and Video Coding applications

Deeply compatible with Modicon Quantum, M340 series PLC, and Schneider EcoStruxure architecture, without the need for additional adapter modules, seamlessly integrated into industrial automation control systems

Supports dual installation methods of standard DIN rail and wall mounted fixation, with a compact appearance that adapts to small control cabinet spaces. The installation is firm and does not occupy too many layout resources

ICD890-00000000 has a high protection level of IP64 and a cast aluminum shell that effectively prevents dust and water. It can be directly deployed in harsh industrial sites such as sorting lines and conveyor belts

Integrated RS232/RS422/RS485 and Ethernet multi communication interfaces, supporting Modbus TCP/RTU protocol, with a data transmission rate of up to 115.2kbits, meeting real-time communication requirements

The working temperature covers 0 ℃~40 ℃, and the humidity tolerance is ≤ 95% (no condensation). It is suitable for high and low temperature fluctuation scenarios such as warehousing and logistics, and its operational stability is not affected by the environment

ICD890-00000000 has a scanning frequency of up to 19.1KHZ and can detect 10 objects per second. A single object can recognize up to 50 one-dimensional codes or 10 two-dimensional codes, making it efficient for high-speed production lines

Built in all-round scanning and automatic focusing function, reading distance of 1.4-3 meters, depth of field up to 1600mm, stable code reading without precise positioning

Supports 24VDC standard industrial power supply, equipped with 2 digital input and 2 digital output interfaces, perfectly linked with sensors and sorting actuators, with strong universality

ICD890-000000 has a 40% barcode contrast (PCS) recognition capability, compatible with multiple types of barcodes such as DataMatrix, EAN, UPC, etc., and suitable for different printing quality scenarios

Built in fault self checking and status monitoring functions, providing real-time feedback on communication, power supply, and code reading abnormalities through LED indicator lights, facilitating quick troubleshooting and maintenance

Adopting electrical isolation design, it has outstanding anti electromagnetic interference capability and can maintain stable image acquisition and data transmission in complex industrial electromagnetic environments

ICD890-000000 has an average time between failures (MTBF) of over 50000 hours, and industrial grade component selection ensures long-term continuous operation, reducing downtime and maintenance frequency

 ICD890-00000000 Image Acquisition Device  Product imag
