AEG MODICON 7628-042.244 Backboard

AEG MODICON 7628-042.244 Backboard

Product Details Introduction

AEG MODICON 7628-042.244 is an industrial backplane (also known as rack/motherboard) under Schneider, designed specifically for Modicon series module interconnection.

As the physical and electrical connection core of the system, it provides a stable installation base and signal transmission channel for I/O modules and processor modules.

Adopting a 5-slot standard design, it can simultaneously carry 5 functional modules, adapting to the configuration requirements of small and medium-sized automation systems.

Compatible with Modicon DTA series (such as DTA200/DTA201/DTA202), supporting flexible configuration of primary/secondary racks.

7628-042.244 has a built-in high-speed backplane bus, which enables real-time data exchange between modules and ensures the transmission of control instructions and acquisition signals without delay.

Provide unified power distribution function to provide stable power supply for mounting modules, simplify system wiring, and reduce the risk of power failure.

Equipped with industrial grade electrical isolation design, it can resist electromagnetic interference and ensure stable communication and power supply between modules under complex working conditions.

Suitable for 24V DC industrial common power supply environment, perfectly matching the power supply requirements of Modicon series modules, compatibility does not require additional debugging.

Adopting standard rack mounted installation, the structure is stable and can withstand industrial site vibration and impact. Installation and disassembly are convenient and efficient.

Support hot swappable module installation, no need to shut down and replace modules during maintenance, reducing system downtime losses.

The working temperature has a wide adaptability range and can operate stably for a long time in high and low temperature, high dust industrial environments, with outstanding reliability.

Compatible with industrial universal protocols such as MODBUS, seamlessly connecting PLC, HMI, and various functional modules, with low system integration difficulty.

In industries such as chemical, power, and metallurgy, module interconnection and signal routing are commonly used as core components in automation control systems.

Modular rack design supports system expansion and can expand the number of slots through master-slave rack linkage to meet business growth needs.

7628-042.244 has been validated in long-term industrial scenarios, with a durable structure and stable performance, and is the core foundational component for building the Modicon system.
