Product Details Introduction

High precision data collection: It can accurately collect analog signals with a measurement error of less than ± 0.1%, suitable for monitoring industrial parameters such as pressure and temperature, and the data accuracy meets the high-precision requirements of oil and gas, chemical and other industries.

Multi signal type compatibility: Supports common industrial signals such as 4-20mA and 0-10V, without the need for additional signal converters. It can directly interface with sensors and transmitters and adapt to various monitoring scenarios.

Triple redundancy ensures stability: adopting TMR architecture, three independent channels synchronously process data, and a single channel failure does not affect the analysis results. It meets SIL 3 safety standards and is suitable for use in high-risk environments.

Quick analysis response: With data processing latency as low as milliseconds, it can output analysis results in real-time. When abnormal parameters occur, it can quickly trigger warnings, which is 20% faster than the response speed of ordinary modules.

Equipped with fault diagnosis: Real time monitoring of its own hardware status, it will actively alarm when there are channel abnormalities or signal distortions, and can also record fault information, making it more convenient to investigate the cause later and reducing maintenance time.

Strong anti-interference ability: The signal channel has 1500V DC isolation protection, which can resist electromagnetic radiation and voltage fluctuations. In workshops with many motors and dense frequency converters, data transmission is still stable.

Wide temperature environment adaptation: The working temperature range is from 40 ℃ to 70 ℃. The circuit board has undergone moisture-proof treatment and can work normally even in high humidity and dusty environments without the need for additional protective equipment.

Support online maintenance: It can be plugged and unplugged with power, and modules or parameters can be replaced or calibrated during system operation without stopping the line. The maintenance process does not affect production and improves equipment utilization.

Flexible docking system: It can seamlessly integrate with the TRICONEX TMR safety control system, support Modbus TCP/IP protocol, and is easy to connect with PLCs and monitoring platforms without extensive program modifications.

High durability design: The casing is made of corrosion-resistant metal material, and key components are selected from industrial grade products. The average time between failures exceeds 150000 hours, making it suitable for long-term continuous monitoring scenarios.

 TRICONEX 3700A Product imag
