MAGNETEK DS316 Driver

MAGNETEK DS316 Driver

Product Details Introduction

product overview

MAGNETEK DS316 is a digital DC drive designed for industrial motor control systems, specifically for high-performance closed-loop or open-loop control applications. It supports regenerative braking and non regenerative working modes, suitable for industrial environments that require high-precision speed and torque control. This driver has been widely used in manufacturing, processing, and material handling systems.

Product Features

High performance control capability

Support closed-loop armature and excitation control to achieve precise adjustment of motor speed and torque, with fast and stable response.

Multiple working modes

Provide regeneration and non regeneration control options, suitable for equipment systems with different energy feedback requirements.

User friendly interface

Equipped with a digital display and parameter setting panel, it is convenient for debugging, parameter adjustment, and operation monitoring.

Complete protection function

Built in overvoltage, undervoltage, overcurrent, overheating, and grounding fault protection mechanisms ensure the safe operation of equipment.

Modular structural design

Compact design, easy to integrate into control cabinets or automation systems, supports multiple installation methods.

Compatible with multiple types of loads

Can drive various DC motors, suitable for constant torque and variable torque application environments.

Typical application areas

Metallurgical and rolling equipment: used for precise speed and tension control in process equipment such as rolling mill main drive and coiling machine

Paper and Textile Machinery: Ensuring Constant Speed Operation and Tension Consistency in Continuous Production Processes

Crane and lifting system: controls the operation of the lifting motor, with fast dynamic response and regenerative braking capability

Rubber and packaging machinery: used to drive the main motor and driven shaft to achieve coordinated operation

Conveying and processing system: Control conveying speed, start stop rhythm, and adapt to variable load conditions

Product imag
