Magnetek 46S03345-0400 Control Armature Interface Module

Magnetek 46S03345-0400 Control Armature Interface Module

Product Details Introduction

1、 Product Overview

Magnetek 46S03345-0400 is an Armature Interface Module used in DC drive systems. This module is typically integrated into industrial DC drives to regulate, control, and monitor armature circuit voltage and current, achieving stable operation and protection of the motor.

It plays a key role in Magnetek's DC drive systems (such as GPD, DCS series, etc.), mainly used for controlling armature voltage output, feedback signal processing, and signal transmission with the main control board.

2、 Technical parameters (typical indicators, specific models may vary slightly)

Input signal type: analog (voltage/current), digital control signal

Output function: Control armature voltage or modulate PWM drive signal

Operating voltage range: 24V or higher (depending on system specifications)

Interface: Terminal or cable connection to the main control module

Additional functions: current limiting, overvoltage/undervoltage detection, armature feedback regulation, fault monitoring

Cooling method: relying on whole machine air cooling or natural cooling

Installation method: Plug in or screw fixed inside the drive main frame

3、 Application scenarios

The Magnetek 46S03345-0400 control armature interface module is widely used in the following industrial equipment and scenarios:

Industrial DC motor drive system

Used to control the acceleration, deceleration, and speed stabilization process of heavy-duty DC motors

Compatible with dynamic braking and regenerative braking circuits

Metal processing equipment

DC drive control in large load equipment such as rolling mills and shearing machines

Printing and papermaking machinery

DC electric drive system for precise control of tension and paper feed speed

Textile machinery

Control warp winding, armature dynamic adjustment, and multi motor synchronization

Material conveying and lifting system

Provide smooth load starting and speed control

Combined with encoder closed-loop feedback for closed-loop speed/torque regulation

Product imag
