Product Details Introduction

1、 Product Overview

Magnetek GPD505V-B034 is a three-phase AC inverter in the GPD 505V series, suitable for industrial drive applications at 460V voltage level, with an output power of 34 HP (horsepower). This model is mainly used to control the speed, torque, and direction of three-phase induction motors, achieving high efficiency, energy saving, and precision control through frequency conversion technology.

2、 Technical specifications (typical)

Input voltage: three-phase 380~460 VAC, 50/60 Hz

Output voltage: 0~460 VAC, variable frequency output

Power level: 34 HP (approximately 25.3 kW)

Output frequency range: 0.1~400 Hz

Control mode: V/f (voltage/frequency) control or vector control

Overload capacity: 150% rated current, lasting for 60 seconds

Cooling method: forced air cooling

Communication interface: Supports expansion cards (such as RS-485, DeviceNet, etc.)

3、 Main product features

1. Advanced vector control technology

Realize precise control of motor torque and speed, especially suitable for high dynamic response scenarios.

Provide sensorless vector control to achieve stable torque output without the need for an encoder.

2. Wide frequency output range

The output frequency can reach 400 Hz, suitable for high-speed motors and special application requirements.

3. Rich protection functions

Built in fault detection and protection mechanisms for overvoltage, undervoltage, overcurrent, overheating, and ground short circuit.

Automatic reset and programmable fault response mechanisms can improve system availability.

4. Easy to set up and debug

Provide a digital operation panel that supports parameter viewing, modification, and storage.

The parameter structure is clear, with quick copying function, suitable for batch debugging.

5. Flexible I/O configuration

Up to 5 digital inputs, 2 analog inputs, 2 relay outputs, and 1 analog output.

All I/O can be functionally mapped through parameters to achieve customized control logic.

6. Built in energy-saving operation mode

Automatically reduce output voltage during light load to lower energy consumption.

Support jumping frequency band (avoiding resonance) and dynamic braking control.

7. Modular design for easy maintenance

Fans, control boards, and other components can be replaced independently, simplifying the maintenance process.

Support hot swappable communication modules.

Product imag
