Product Details Introduction

EATON PL9-C10-2-DC miniature circuit breaker is a bipolar miniature circuit breaker designed specifically for DC applications, widely used in DC distribution systems to provide overload and short-circuit protection. The following is a detailed introduction of the model:

1、 Basic Product Information

Model: PL9-C10-2-DC

Type: Miniature Circuit Breaker (MCB)

Number of poles: 2 poles (bipolar)

Rated current: 10A

Rated voltage: typically supports up to 220V DC (single pole) or 440V DC (two pole series)

Release curve: C-type (suitable for light to moderate inductive loads)

Installation method: DIN rail installation

Standard certification: Complies with IEC/EN 60947-2 and related DC circuit breaker standards

2、 Product Features

Specially designed for DC circuits, the internal arc extinguishing system of the circuit breaker is optimized to ensure safe and fast extinguishing of DC arcs.

Bipolar disconnection, while disconnecting both poles, ensures safe isolation of the DC power supply system.

C-type trip curve, suitable for loads with starting surges such as motors and relays.

High breaking capacity, capable of withstanding large short-circuit currents.

Compact design, easy to install in standard distribution boxes and control cabinets.

Product imag
