EATON PL9-C6-2-DC Miniature Circuit Breaker

EATON PL9-C6-2-DC Miniature Circuit Breaker

Product Details Introduction

EATON PL9-C6-2-DC miniature circuit breaker is a bipolar miniature circuit breaker designed specifically for DC systems, suitable for overload and short circuit protection of DC power supply circuits, commonly used in industrial, communication, and new energy fields. Here is a detailed introduction:

1、 Basic Product Information

Model: PL9-C6-2-DC

Type: Miniature Circuit Breaker (MCB)

Number of poles: 2 poles (bipolar)

Rated current: 6 A

Rated operating voltage: typically supports up to 220V DC (single pole) or 440V DC (two pole series)

Release characteristics: C-type release curve (suitable for moderate inductive loads)

Installation method: Standard DIN rail installation

Certification standard: Complies with IEC/EN 60947-2 or IEC/EN 60898 (requirements for DC applications)

2、 Product Features

Specially designed for DC: optimized internal arc extinguishing device of circuit breaker, suitable for DC arc characteristics, ensuring fast and safe disconnection of DC circuit.

Bipolar disconnection: Simultaneously disconnect both poles to ensure safe isolation of the circuit breaker in the DC system.

C-type trip: allows moderate starting current surge, suitable for inductive loads such as DC motors and relays.

High breaking capacity: It has good short-circuit protection capability and meets the needs of industrial environments.

Compact structure: Designed to meet the space requirements of modern distribution boxes and control cabinets, easy to install and maintain.

Product imag
