TRICONEX 3625C1 Controller Module

 TRICONEX 3625C1 Controller Module

Product Details Introduction

Triple redundancy control safety: using TMR architecture, three independent control units synchronously calculate and cross calibrate data, single unit failure does not interrupt the system, suitable for high-risk scenarios such as oil and gas, chemical industry, etc., in compliance with SIL 3 safety standards.

Multi channel centralized control: Integrated with 32 digital I/O channels (input and output can be flexibly configured), each supporting 24V DC signals, capable of simultaneously controlling devices such as valves and sensors without the need for additional expansion modules, saving space.

Fast instruction response: Control signal processing delay is as low as milliseconds, emergency shutdown, interlock protection and other instructions can be executed quickly. After being used by a chemical enterprise, the equipment abnormal response speed is 15% faster than the old model.

Built in fault protection: No need for external protective components, equipped with overcurrent and short-circuit protection. In case of channel failure, the output of the circuit will be automatically cut off to avoid affecting the overall system and reduce maintenance costs by 20%.

Strong anti-interference ability: Each signal is isolated at 1500V DC, which can prevent electromagnetic radiation and voltage fluctuations. In workshops with multiple frequency converters and dense motors, the signal error rate is only 0.01%, and the operation is stable.

Support online maintenance: The module can be plugged and unplugged with power on, and can be replaced or repaired during operation; Each route has LED lights to display the status. When there is a fault, the red light will turn on, and the problem can be located within a few minutes without stopping the line for troubleshooting.

Can be used in a wide temperature environment: it can work normally from -40 ℃ to 70 ℃. The circuit board has been treated with moisture-proof measures, and it can also be used for a long time in high humidity and dusty control cabinets without the need for additional temperature control equipment.

Flexible docking system: It can directly connect to the TRICONEX TMR safety control system, support Modbus TCP/IP protocol, and connect with PLC and monitoring platform without changing the program, with high integration efficiency.

Comprehensive self checking function: automatically detects hardware status upon startup, monitors channel load in real-time during operation, records fault information, and provides a basis for later troubleshooting, reducing maintenance time.

High durability design: The casing is made of corrosion-resistant materials, and the key components are selected from industrial grade durable models. The average time between failures exceeds 150000 hours, making it suitable for long-term continuous production scenarios.

 TRICONEX 3625C1 Product imag
