AMAT Applied Materials 0100-90311 Interface Module

AMAT Applied Materials 0100-90311 Interface Module

Product Details Introduction

1. Adaptation scenarios and functions (0100-90311)

Equipment adaptation: Match AMAT semiconductor process equipment (such as etching and deposition machines) as a signal hub between the main control unit and peripherals, and adapt to the connection requirements of sensors, actuators, and control modules.

Process compatibility: Focusing on the semiconductor clean room environment, adapting to signal transmission for vacuum pumping, gas transportation and other processes, supporting linkage with AMAT SmartFactory yield management system.

Core function: Implement bidirectional conversion and transmission of digital/analog signals, undertake control command issuance and equipment status data feedback functions, and ensure the coordinated operation of multiple components.

2. Accuracy and Performance (0100-90311)

Transmission performance: Supports RS-232/RS-485 serial interface and Ethernet port, with a communication distance of up to 1000 meters for RS-485, adaptive Ethernet speed of 10/100Mbps, and adjustable baud rate of 300-115200bps.

Protocol compatibility: Supports Modbus RTU master-slave response protocol, compatible with TCP, UDP, HTTP and other network protocols, and can be connected to AMAT device PLC system for remote monitoring.

Stable operation: Built in signal isolation circuit (isolation voltage ≥ 1000VDC), strong anti-interference ability, mean time between failures (MTBF) exceeding 5000 hours, suitable for industrial grade continuous operation requirements.

3. Structure and Protection (0100-90311)

Protection design: The shell is made of industrial grade flame-retardant material, with anti-static (ESD) and electromagnetic interference (EMI) design, suitable for the complex electromagnetic environment of semiconductor workshops.

Installation adaptation: Compact structure (size approximately 90 × 50 × 18mm), supporting DIN35mm rail installation, with foolproof design of wiring terminals to avoid module damage caused by misconnection.

Easy maintenance: equipped with status indicator lights (power, communication, fault), supports debugging parameters through Windows configuration software, and provides API function libraries for secondary development.

AMAT Applied Materials 0100-90311 Product imag
