AMAT Applied Materials 0100-00156 Isolation Amplifier

AMAT Applied Materials 0100-00156 Isolation Amplifier

Product Details Introduction

1. Adaptation scenarios and functions (0100-00156)

Equipment adaptation: Matching AMAT semiconductor process equipment (such as etching and deposition machines), used for signal isolation and amplification between sensors (such as pressure and temperature sensors) and the main control unit to avoid interference signals affecting control accuracy.

Process compatibility: Focusing on the strong electromagnetic environment of semiconductor clean workshops, adapting to scenarios such as vacuum chamber pressure monitoring and reaction gas flow signal processing, supporting seamless integration with AMAT equipment PLC systems.

Core function: Implement electrical isolation and linear amplification of analog signals (such as 0-5V, 4-20mA), block high and low voltage circuit interference, and ensure the accuracy of process parameter acquisition and transmission.

2. Accuracy and Performance (0100-00156)

Isolation performance: Isolation voltage ≥ 2500VDC (input-output), ≥ 1500VDC (input-output), isolation resistance ≥ 10 ¹² Ω, effectively blocking common mode interference and ground loop noise.

Amplification accuracy: Voltage gain error ≤ 0.1%, non-linear error ≤ 0.05% FS, temperature drift ≤ 50ppm/℃ (-20-60 ℃), ensuring high linearity even after signal amplification, suitable for 3x nanometer process parameter monitoring requirements.

Signal compatibility: the input supports 0-10V voltage signal, 4-20mA current signal, and the output can be set to 0-5V/0-10V/4-20mA through the dial switch to adapt to the signal specifications of different sensors and the main control unit.

3. Structure and Protection (0100-00156)

Protection design: The shell is made of industrial grade flame-retardant ABS material, with anti-static (ESD) and electromagnetic interference (EMI) design, and has passed EMC testing (EN 55032 Class B) to adapt to the complex electromagnetic environment in the workshop.

Installation adaptation: Compact structure (size approximately 80 × 50 × 20mm), supporting DIN35mm rail installation, with screw locking design for wiring terminals to prevent loose wiring caused by vibration.

Easy maintenance: equipped with power supply and signal status indicator lights, supporting direct measurement of output signals through a multimeter to determine module operating conditions, without the need to disassemble the equipment for preliminary troubleshooting.
