AMAT Applied Materials 0090-00011 Main Framework Interface Module

AMAT Applied Materials 0090-00011 Main Framework Interface Module

Product Details Introduction

1. Adaptability and core functions (0090-00011 main framework interface module)

Adaptation scenario: As a dedicated interface module for the main framework of AMAT equipment, it is highly likely to be used for signal/data transfer between the main framework and subsystems (power supply, IO card, sensor) of semiconductor machines (such as etching and deposition equipment), achieving collaborative linkage among various components

Framework compatibility: It is expected to adapt to the AMAT standard main framework structure (such as the 300mm equipment universal framework), with interface layout matching the internal installation holes of the main framework, and can be directly integrated into existing equipment frameworks to reduce renovation costs

Functional positioning: Serving as the "signal hub" between the main framework and external devices, supporting control command issuance, status data feedback, and adapting to core operational requirements such as equipment start stop and process parameter adjustment

2. Interface configuration and transmission performance (0090-00011 main framework interface module)

Interface type: It may integrate multiple sets of industrial grade interfaces, such as RS-485 serial interface, Gigabit Ethernet port, power interface, taking into account data transmission and power supply requirements, referring to the "multi interface integration" feature of modules in the same series

Transmission rate: The data transmission rate is expected to reach 100Mbps to 1Gbps, meeting the real-time communication requirements between the main framework and subsystems, and avoiding process control delays; Signal transmission delay is controlled in milliseconds to meet the timing requirements of semiconductor precision machining

Protocol support: Compatible with industrial communication protocols such as Modbus and Profinet, it can seamlessly integrate with AMAT device control units and third-party monitoring systems to ensure data exchange stability

3. Structure and Protection Design (0090-00011 Main Framework Interface Module)

Structural characteristics: Adopting a compact design to adapt to the limited installation space inside the main frame; Metal casing (such as aluminum alloy) enhances structural strength and can withstand slight vibrations during equipment operation, avoiding interface looseness

Protection capability: equipped with anti-static (ESD) and electromagnetic interference (EMI) design, blocking the interference of electromagnetic signals in the semiconductor workshop on interface transmission through shielding coatings or isolation circuits; Some interfaces may come with dust covers to reduce the impact of dust

Installation convenience: Supports rail or screw fixed installation, with foolproof interface design (such as color differentiation and shape adaptation for different interfaces) to avoid module damage caused by accidental insertion

AMAT Applied Materials 0090-00011 Product imag
