PCS105PS-400 power module

PCS105PS-400 power module

Product Details Introduction

Product features of PCS105PS-400 power module

1. The rated power is 105kW, and the peak power can reach 116kW, with a long-term overload capacity of 110%, meeting the requirements of short-term high load scenarios.

2. Adopting a three-level topology structure, the energy conversion efficiency is as high as 98.5%, significantly reducing energy loss and improving system energy efficiency.

3. Supports bidirectional conversion between AC and DC, enabling dual functions of AC to DC charging and DC to AC power supply/grid connection.

The DC side voltage adaptation range is wide, covering 615-950V (three-phase three wire)/650-950V (three-phase four wire), compatible with multiple types of batteries.

5. The rated voltage on the AC side is 400Vac, with a voltage fluctuation range of ± 15% and a frequency support of 50/60Hz ± 10%, suitable for different power grid environments.

6. The power factor can reach ± 1~1, the current distortion rate is less than 3% (rated power), the output power quality is excellent, and it meets the grid access standards.

7. Support seamless off grid switching, coupled with STS to provide uninterrupted backup power supply, ensuring continuous power supply for critical loads.

8. It has the ability to ride through low/high voltage, and is not easily disconnected from the power grid when the voltage is abnormal, enhancing the stability of power grid operation.

9. Integrate and improve protection functions, covering overvoltage, undervoltage, overload, overcurrent, short circuit, overheating, etc., and have islanding detection capability.

10. Support multi module parallel expansion, up to 12 parallel units can form a 1.2MW system, suitable for the needs of medium and large-scale energy storage projects.

11. Equipped with CAN/RS485/Ethernet multiple communication interfaces, it can efficiently link with BMS, EMS, and upper level monitoring systems.

12. Adopting intelligent air-cooled heat dissipation design, the working temperature adaptability range is -30 ℃~55 ℃, and it can operate stably within an altitude of 4000m (with derating beyond 2000m).

13. The protection level reaches IP20, and the shell is made of high-strength materials with strong electromagnetic interference resistance, suitable for complex industrial environments.

14. Supports both front and rear wiring methods, with a compact structure (optional size) for easy on-site installation and maintenance.

15. Supports three modes: local manual, local automatic, and remote control, with flexible operation and adaptability to different operation and maintenance scenarios.

PCS105PS-400 Product imag

PCS105PS-400 ontroller Module
