AEG Modicon AS-BADU-206 Analysis Input Module

AEG MODICON AS-BADU-206 Analysis Input Module

Product Details Introduction

The AEG Modicon AS-BADU-206 is an industrial grade multifunctional input module belonging to the Modicon Logistat/Tsx Compact series. It is designed for precise acquisition of analog and discrete signals in industrial fields, with stable and reliable performance.

The core configuration includes 4 high-speed analog input channels, compatible with ± 10V voltage signals and ± 20mA current signals. The AEG Modicon AS-BADU-206 can directly interface with various sensors such as pressure and temperature.

Partial versions have expanded to include 6 discrete inputs and 6 relay outputs. The AEG Modicon AS-BADU-206 integrates signal acquisition and control execution, making it suitable for small and medium-sized automation scenarios.

The input voltage standard is compatible with 24VDC industrial power supply, and the current acquisition range covers 4-20mA standard signals. The AEG Modicon AS-BADU-206 has strong compatibility and does not require additional signal converters.

The industrial working temperature range is -20 ℃~60 ℃, and the storage temperature is -40 ℃~70 ℃. The AEG Modicon AS-BADU-206 is suitable for extreme high and low temperature conditions and transportation and storage needs.

Compatible with Modicon 984 series and Tsx Compact platform, AEG Modicon AS-BADU-206 seamlessly connects to the corresponding PLC rack, plug and play, and easy system expansion.

Compact in size (approximately 12.7cm x 7.6cm x 15.2cm), with a net weight of only 0.3-0.49kg, AEG Modicon AS-BADU-206 saves control cabinet space and is suitable for dense installation scenarios.

Compliant with Class I Div 2 safety standards and ABCD group classification, AEG Modicon AS-BADU-206 has strong electromagnetic interference resistance and is suitable for hazardous industrial environments.

Supporting high-speed data acquisition and fast analog signal response, AEG Modicon AS-BADU-206 meets the sampling rate requirements for real-time monitoring of industrial processes.

Adopting a sturdy casing, the AEG Modicon AS-BADU-206 is shock and vibration resistant, with high long-term reliability and a long average time between failures.

 AEG MODICON AS-BADU-206 Product imag
