AMAT Applied Materials 0100-90378 Interface Module

AMAT Applied Materials  0100-90378 Interface Module

Product Details Introduction

1. Interface configuration and adaptability (0100-90378 interface module)

Core interface: Referring to the characteristics of the same series 0100-20100 models, it is expected to integrate RS-232/RS-485 serial interface and Ethernet port, which can adapt to the signal interaction requirements of sensors, actuators, and main control units in semiconductor equipment

Equipment adaptation: As a dedicated module for the AMAT 0100 series, it is highly likely to be compatible with 300mm deposition and etching machines (such as P5000 and Producer series platforms), accurately matching the communication interface specifications of the equipment control unit

Protocol compatibility: It is expected to support multiple industrial communication protocols such as I2C, SPI, UART, etc., and can seamlessly integrate with different brands of peripherals, adapting to multi device collaboration scenarios in semiconductor manufacturing

2. Transmission performance and scalability (0100-90378 interface module)

Transmission rate: Referring to the general standard of industrial control modules, the baud rate is expected to cover 9600bps to 115200bps, supporting a data throughput of 1Mbps, and meeting the real-time signal transmission requirements during wafer processing

Expansion design: modular slots may be reserved, which can flexibly accommodate functional daughter cards such as fiber optic conversion and analog acquisition, adapting to the later functional upgrade needs of semiconductor equipment

Data format: Supports universal data formats such as 8N1 and 8E1, compatible with signal encoding logic of different devices, and reduces system integration complexity

3. Stability and Protection Design (0100-90378 Interface Module)

Anti interference performance: Using differential signal transmission technology, it can block the influence of electromagnetic interference on signals in semiconductor workshops, ensuring the accuracy of process parameter transmission

Hardware protection: It is expected to have built-in overvoltage and overcurrent protection circuits, combined with anti-static design, to avoid external instantaneous impact damage to the core components of module 0100-90378

Status monitoring: Equipped with LED indicator lights, it can display real-time working status such as power on/off and data transmission. Combined with fault self diagnosis function, it simplifies equipment maintenance process

AMAT Applied Materials 0100-90378 Product imag
