Motorola MVME332XT 01-W3475B-02D Bus Controller

Motorola MVME332XT 01-W3475B-02D Bus Controller

Product Details Introduction

Motorola MVME332XT 01-W3475B-02D Bus Controller

Product Overview

Motorola MVME332XT (model 01-W3475B-02D) is a bus controller module based on the VMEbus architecture, used for MVME332 series single board computer systems. This module is mainly responsible for data scheduling, address decoding, interrupt management, and bus arbitration of the VME bus, achieving high-speed and reliable communication between the CPU module and other I/O, storage, and expansion boards. MVME332XT ensures stable bus operation of the system in a multi module environment and is a key component of embedded control, industrial automation, and real-time data processing systems.

Technical Specifications

Bus type: VMEbus standard, supports 16/32-bit data transmission

Function:

Bus arbitration and address decoding

Interrupt management and priority control

DMA data transfer support

Compatibility: Compatible with MVME332 series CPU modules and other VME expansion modules

Interface: VMEbus slot interface, supporting A16/A24/A32 address space

Electrical and environmental characteristics: Industrial grade design, strong anti-interference ability, suitable for long-term continuous operation

System support: Can be used in conjunction with real-time operating systems such as VxWorks and pSOS

Application scenarios

Industrial automation system

Provide data bus management between CPU, multi-channel I/O modules, and servo controllers.

Machine Tool and Robot Control

Manage data communication and interrupt scheduling for multi axis motion control systems.

Testing and Measurement System

Perform high-speed data acquisition and processing in experimental equipment or production line testing systems.

Communication and Embedded Network Systems

Used for data bus control and synchronization in distributed embedded systems.

Energy and Power Management System

Implement bus data scheduling and control for power generation equipment, substations, and distribution systems.
