Motorola MVME333S-2 Controller Module

Product Overview

Motorola MVME333S-2 is an embedded controller module based on the VMEbus architecture, belonging to the MVME333 series of single board computers. This module integrates CPU, memory, timer, and multiple I/O interfaces, and is used in industrial automation, testing and measurement, communication systems, and embedded real-time control scenarios. MVME333S-2 can serve as the core processing unit of the system, providing reliable computing and control capabilities, while seamlessly collaborating with VME bus and other expansion modules.

Technical Specifications

Processor: Motorola MC68040 or MC68LC040 (depending on the model)

Memory:

RAM：4 MB – 16 MB， scalable

ROM/Flash：256 KB – 2 MB， Used for firmware and bootloader

NVRAM: with real-time clock function

Bus interface: VMEbus standard, supports 16/32-bit data transmission, A16/A24/A32 address space

I/O interface:

Multi channel serial interface (RS-232/RS-422)

Parallel Interface

Timer and watchdog

Control function:

Support interrupt management and DMA data transfer

Built in self-test function (BIT)

Compatibility: Supports real-time operating systems such as VxWorks and pSOS

Work environment: Industrial grade design, suitable for long-term continuous operation

Application scenarios

Industrial Automation and Process Control

Control production line equipment, PLC system, and process monitoring.

Machine Tool and Motion Control System

Multi axis synchronous control, pulse output, and real-time motion control.

Testing and Measurement System

Data collection, experimental control, and instrument management.

Communication system and network equipment

Telecommunications switching nodes, embedded communication controllers.

Energy and Power Systems

Power generation equipment, substation control, and automation management.

Research and Simulation System

Real time embedded control and experimental simulation platform.

Motorola MVME333S-2 Controller Module Product imag
