BENTLY 3500/22M 138607-01 Transient Data Interface

BENTLY  3500/22M 138607-01 Transient Data Interface

Product Details Introduction

Ultra precise transient data acquisition: BENTLY 3500/22M (138607-01) is a professional transient data interface that can quickly collect transient data such as vibration, speed, displacement, etc. of rotating machinery, such as sudden vibration signals of steam turbines and speed fluctuation data of motors. It captures data quickly and accurately, providing accurate basis for equipment fault analysis.

Compatible with 3500 Monitoring System: Designed specifically for BENTLY 3500 mechanical protection systems, it can seamlessly integrate with 3500 series monitoring modules without additional debugging to quickly expand transient data acquisition capabilities. It is particularly suitable for scenarios such as power plants and chemical plants that rely on the 3500 system.

Multi signal type compatibility: supports various analog and digital signal inputs such as vibration, displacement, and speed, and can connect different types of monitoring devices such as acceleration sensors and eddy current probes. It can collect multi-dimensional mechanical data without changing interfaces and has strong adaptability.

Stable operation in harsh environments: capable of working within a temperature range of 0 ℃~65 ℃, dustproof, moisture-proof, and resistant to electromagnetic interference. The dust, humid environment in industrial sites, as well as electromagnetic radiation during equipment operation, will not affect its data acquisition stability and are not prone to malfunctions.

Fast data transmission speed: With high-speed data transmission capability, the collected transient data can be quickly transmitted to the upper computer or data analysis system. For example, in case of sudden equipment abnormalities, the vibration peak data can be promptly transmitted to the monitoring platform to buy time for emergency response.

Modular installation saves space: Adopting the BENTLY 3500 system standard modular design, it can be directly installed in the 3500 framework, with a compact layout with other monitoring modules, without occupying additional control cabinet space, suitable for scenarios with high system integration.

Fault warning and easy troubleshooting: equipped with status indicator lights, whether the power supply is on or off, whether data transmission is normal, and whether the interface is faulty can be preliminarily judged by looking at the lights; It can also provide feedback on fault codes through the system, so that maintenance personnel do not need to inspect each line one by one, quickly locate the problem, and shorten the troubleshooting time.

Wide voltage power supply easy to adapt: supports 24V DC standard industrial power supply, directly matches with commonly used control cabinet power supply on site, no need to customize special power supply, simple wiring, no need to repeatedly adjust power supply parameters during installation, saving time and effort.

Data storage assistance analysis: It can be used in conjunction with the system to temporarily store transient data. When the device encounters an abnormality, it can save key data before and after the fault. When analyzing the cause of the fault and tracing the fault process, it has complete data support, which facilitates accurate diagnosis.

Dual guarantee of compliance and durability: Compliant with industrial equipment safety certification standards, made of industrial grade wear-resistant and corrosion-resistant materials, capable of withstanding mechanical vibration and on-site impact, with a long average time between failures. Long term use in rotating machinery monitoring scenarios is also worry free, reducing maintenance costs.

BENTLY  3500/22M 138607-01 Product imag
