Enterasys X-CM-00 Control Module

Extreme Networks  X-CM-00 Control Module

Product Details Introduction

1、 Quick overview of core parameters

Model attribute: Enterasys X-CM-00 is a modular switch core control module under Extreme Networks, providing a central processing and management hub for chassis switches, and is a critical functional module.

Hardware positioning: Adopting a dedicated control chip architecture, integrating a data forwarding engine and management interface, usually with independent processors, memory, and storage units, providing computing and control support for the entire switch.

Key features: Supports hot swappable design, can be replaced while the switch is running, ensuring business continuity; Equipped with redundant deployment capability, coupled with dual control module configuration, it can achieve automatic fault switching.

2、 Core functions and values

Central control: As the "brain" of the switch, responsible for processing machine configuration instructions, data forwarding strategies, and port status management, coordinating the coordinated operation of I/O expansion modules and upstream modules.

Management Support: Equipped with core components of the network management system, it supports various management methods such as Web UI, CLI, SNMP, etc., providing underlying computing power support for port mirroring, VLAN configuration, traffic monitoring, and other functions.

Redundancy guarantee: Supports hot backup of primary and backup control modules. In the event of a primary module failure, it can be switched to the backup module in milliseconds to avoid network control interruptions and improve the reliability of the core layer network.

3、 Typical use

Large chassis switch: Suitable for Enterasys high-end modular switch chassis (such as S-Series or X-Series chassis), deployed as the core control unit in enterprise data centers and campus network core layers.

Key Business Network: Used in scenarios such as government, finance, and energy that require high stability, the core network control is guaranteed to be uninterrupted through dual module redundant configuration, supporting the continuous operation of business systems.

Network expansion and upgrade: When the performance of the original control module is insufficient or faulty, it can be used as a replacement or upgrade module to improve the processing capacity and management efficiency of the switch.

Extreme Networks X-CM-00 Product imag
