AMAT Applied Materials DNP-CPCI-2 Scanner Module

AMAT Applied Materials DNP-CPCI-2 Scanner Module

Product Details Introduction

Product Overview

The AMAT Applied Materials DNP-CPCI-2 scanner module is a dedicated control module based on the CompactPCI (CPCI) bus architecture, used in semiconductor devices as the core unit for high-speed data acquisition and signal scanning. This module is mainly used for monitoring, collecting, and processing a large number of analog/digital signals during the process, ensuring the real-time and stability of process control. It is usually installed inside the CPCI control chassis and works in conjunction with other processor boards and I/O boards.

Technical parameters (speculated and organized)

Bus interface: Compatible with CompactPCI 2. x standard, supports 32/64 bit bus transmission.

Functional positioning: As a "scanner module", it has the ability to collect multi-channel signals and synchronize scanning, adapting to the high-speed requirements of process control.

Signal type: Supports multiple analog inputs/digital inputs/outputs, capable of real-time acquisition and time-sharing scanning.

Data processing: may integrate FPGA or DSP resources for front-end data processing, filtering, and buffering.

Synchronization feature: Supports synchronization with process controllers, trigger signals, and external clocks to achieve coordinated operation of multiple modules.

Cooling method: relying on CPCI chassis air cooling for heat dissipation, some versions may have heat sink reinforcement design.

Version revision: DNP-CPCI-2 may have revised versions such as Rev. A/B, which may vary in terms of channel count, interface layout, or firmware.

Application scenarios

Semiconductor manufacturing process monitoring: used for signal acquisition and process monitoring of process equipment such as etching, CVD, PVD, etc.

Vacuum/gas/liquid system: Scan and collect sensor signals such as pressure, flow rate, valve status, etc.

RF/power monitoring: Real time scanning of feedback signals from RF matching devices and power units for closed-loop control.

Equipment integration control: Cooperate with the CPCI bus main control CPU board to form a complete real-time control and acquisition system.

AMAT Applied Materials DNP-CPCI-2 Product imag
